1500x3000mm Fiber Laser Cutter 3000W CNC Sheet Metal Cutting Machine

Product Details

Place of Origin: China

Brand Name: RayLaser

Certification: CE

Payment & Shipping Terms

Minimum Order Quantity: 1

Price: Negotiation

Packaging Details: Wooden

Delivery Time: 7-30days

Payment Terms: T/T

Supply Ability: Sets/M

Get Best Price

Product Details

Product Description

Highlight:
                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                Gantry Sheet Metal Laser Cutting Machine, Laser Cutting Machine 1500x3000 Mm, 3000W Gantry Fiber Laser Cutter


Application:	LASER CUTTING	Applicable Material:	Metal
Condition:	New	Laser Type:	Fiber Laser
Cutting Area:	1500mm*3000mm	Cutting Speed:	0-500000mm/min
Graphic Format Supported:	AI, PLT, DXF, BMP, Dst, Dwg, LAS, DXP	Cutting Thickness:	0-30mm
CNC Or Not:	Yes	Cooling Mode:	WATER COOLING
Control Software:	Cypcut	Laser Source Brand:	RAYCUS
Laser Head Brand:	Raytools	Servo Motor Brand:	Yaskawa
Guiderail Brand:	HIWIN	Weight (KG):	3500 KG
Key Selling Points:	High-accuracy	Optical Lens Brand:	Wavelength
Warranty:	2 Years	Applicable Industries:	Garment Shops, Building Material Shops, Manufacturing Plant, Machinery Repair Shops, Food & Beverage Factory, Home Use, Printing Shops, Construction Works , Energy & Mining, Advertising Company
Machinery Test Report:	Provided	Video Outgoing-inspection:	Provided
Warranty Of Core Components:	1 Year	Core Components:	Motor, Gearbox
Mode Of Operation:	Continuous Wave	Configuration:	3-axis
Products Handled:	Sheet Metal	Feature:	Water-cooled

Application:	LASER CUTTING
Applicable Material:	Metal
Condition:	New
Laser Type:	Fiber Laser
Cutting Area:	1500mm*3000mm
Cutting Speed:	0-500000mm/min
Graphic Format Supported:	AI, PLT, DXF, BMP, Dst, Dwg, LAS, DXP
Cutting Thickness:	0-30mm
CNC Or Not:	Yes
Cooling Mode:	WATER COOLING
Control Software:	Cypcut
Laser Source Brand:	RAYCUS
Laser Head Brand:	Raytools
Servo Motor Brand:	Yaskawa
Guiderail Brand:	HIWIN
Weight (KG):	3500 KG
Key Selling Points:	High-accuracy
Optical Lens Brand:	Wavelength
Warranty:	2 Years
Applicable Industries:	Garment Shops, Building Material Shops, Manufacturing Plant, Machinery Repair Shops, Food & Beverage Factory, Home Use, Printing Shops, Construction Works , Energy & Mining, Advertising Company
Machinery Test Report:	Provided
Video Outgoing-inspection:	Provided
Warranty Of Core Components:	1 Year
Core Components:	Motor, Gearbox
Mode Of Operation:	Continuous Wave
Configuration:	3-axis
Products Handled:	Sheet Metal
Feature:	Water-cooled

1500x3000mm Fiber Laser Cutter 3000W CNC Sheet Metal Cutting Machine

Gantry Sheet Metal Laser Cutting Machine 1500x3000mm 3000W Fiber Laser Cutter

Portable Gantry Fiber Laser Cutter with high-accuracy cutting capabilities for various metal materials.

Key Specifications

Application	LASER CUTTING
Applicable Material	Metal
Laser Type	Fiber Laser
Cutting Area	1500mm × 3000mm
Cutting Speed	0-500,000mm/min
Cutting Thickness	0-30mm
CNC Control	Yes
Cooling Mode	WATER COOLING
Warranty	2 years (1 year for core components)

Machine Features

Complete set of laser cutting equipment with fiber laser, chillers, cutting head, and control system
Gantry mobile structure with two axes linkage and three axes control
X and Y axis use AC servo motor to drive rack and rack feed
Z-axis tracks workpiece surface with floating mechanism
High-quality imported components including servo motors, ball screws, and linear guides
German brand laser-specific numerical control system with specialized cutting software
Capable of cutting stainless steel, carbon steel, galvanized steel, aluminum, titanium and other metals
Water-cooled system for efficient heat management
Anti-crash laser cutting head with auto-tracking system

Component Specifications

Component	Brand
Fiber Laser Source	MAX/RAYCUS
Laser Cutting Head	RAYTOOLS/OSPRI
AC Servo Motor and Driver	Haijie
Linear Guide Rail	HIWIN
Water Cooling Machine	HANLI
CNC Controller	Cypcut
Pneumatic System	SMC
Electrical Components	Schneider

Machine Structure

The machine tool frame is welded from high-quality steel plate and tube, processed by Vibratory Stress Relief and precision machining. Features excellent shake-proof capacity, rigidity, and stability for high-speed operation and accurate cutting.

CNC Controller

Full-featured open-loop control system with easy debugging, safe production, and rich functionality. Supports memory cache and has a powerful cutting process database for efficient operation with various materials.

Laser Cutting Head

Features anti-crash function, high-pressure resistance, auto-tracking system, and protective features to ensure cutting quality and extend lens life.

Laser Source

Low energy consumption with photoelectric conversion rate up to 30-35%
Only 30-35% power consumption of traditional CO2 lasers
Minimal maintenance required
Up to 100,000 hours lifespan

Water Cooling Unit

Large cooling capacity with stable performance, clean water quality, and good heat exchange with fiber laser. Includes linkage signal for laser protection.
