Product Details
Place of Origin: China
Brand Name: RayLaser
Certification: CE
Model Number: EP 6024 Pro
Payment & Shipping Terms
Minimum Order Quantity: 1
Price: Negotiation
Packaging Details: Wooden
Delivery Time: 7-30days
Payment Terms: T/T
Supply Ability: 10-30Sets/M
OEM: |
CUSTOMIZED |
Advantage: |
Efficient And Economical |
Power Scale: |
Medium Power Laser Cutting |
ACCELERATION: |
2g |
PRECISION: |
0.03mm/m |
SPEED: |
140m/s |
CUTTING AREA: |
6000mm(L) X 230mm(DIA.) |
ELECTRONIC CABINETS: |
Separated Closed Loop |
OEM: |
CUSTOMIZED |
Advantage: |
Efficient And Economical |
Power Scale: |
Medium Power Laser Cutting |
ACCELERATION: |
2g |
PRECISION: |
0.03mm/m |
SPEED: |
140m/s |
CUTTING AREA: |
6000mm(L) X 230mm(DIA.) |
ELECTRONIC CABINETS: |
Separated Closed Loop |
The Machine's Technical Solution please refer to the Attachment:
Machine: Features, Advantages and Benefits
Shanghai Raylaser's laser cutting machine systems will boost your output and ensure high quality and increased productivity.
The laser cutting machine features high precision, high speed, narrow tilt, small heated zone, high flexibility, low maintenance cost,etc.
Mainly Applications: hand railing, bikes, windows, metal fabrication, electronics manufacturing, the automotive industry, and aerospace.
1) Configuration and Specification
Machine Configuration
| No | Key parts | Brands |
| 1 | System | Bochu Cypcut |
| 2 | Laser source | Raycus, Max, IPG |
| 3 | Laser cutting head | Raytools Boci Ospri WSX |
| 4 | Chiller | Hanli/S&A |
| 5 | Servo Motor (1300w+850w+400w) | Yaskawa Inovance |
| 6 | Reducer | MOTOVARIO |
| 7 | Rack and Pinion | LEADER/YYC |
| 8 | Rail guideway | HIWIN |
| 9 | Standard electrical parts | Schneider/Shanghai Electric |
| 10 | Electrical proportional valve | O2(<10bar) |
Technical Specification
| No. | Key Performance | Specification |
| 1 | Working area | 6000mm (L) ×230mm (Dia.) |
| 2 | X axis length | 400mm |
| 3 | Y axes length | 6010mm |
| 4 | Z axis length | 300mm |
| 5 | Positioning accuracy | ≤0.03mm |
| 6 | Repeat positioning accuracy | ≤0.02mm |
| 7 | Max.accumulated speed | 100m/min |
| 8 | Max.Acceleration | 1.2G |
| 9 | Load Bearing Capacity | 1500KG |
| 10 | Overall weight | 2500Kg |
| 11 | Machine overall dimensions | L12800mm*W1500mm*H1860mm |
| 12 | Power supply | AC380V/50Hz/≤50KVA |
| 13 | Rating | IP54 |
With over 20 years of industrial knowledge, we are committed to providing top-notch solutions that meet your manufacturing expectations.
4) High Standard Quality Process
The manufacturing processes of Laser Cutting Machine is the integration of mechanical, optical, electrical, pneumatic, and fluidic systems!
With our industrial Standardized Production Processes.
A specialized production line, high quality compoments, and experienced techincians come together to craft sophisticated, reliable machinery for our customers.
We committed to deliver quality, reliability and excellent performance.
