1500x3000mm Gantry CNC Fiber Laser Cutting Machine for Metal

Product Details

Place of Origin: China

Brand Name: RayLaser

Certification: CE

Payment & Shipping Terms

Minimum Order Quantity: 1

Price: Negotiation

Packaging Details: Wooden

Delivery Time: 7-30days

Payment Terms: T/T

Supply Ability: Sets/M

Get Best Price

Product Details

Product Description

Highlight:
                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                3000mm Cutting Area CNC Fiber Laser, 1500mm Cutting Area FiberGantry Fiber Laser, Gantry Cnc Fiber Laser Cutter


Application:	LASER CUTTING	Applicable Material:	Metal
Condition:	New	Laser Type:	Fiber Laser
Cutting Area:	1500mm*3000mm	Cutting Speed:	0~100m/min
Graphic Format Supported:	AI, PLT, DXF, BMP, Dst, Dwg, LAS, DXP	Cutting Thickness:	0~30mm
CNC Or Not:	Yes	Cooling Mode:	WATER COOLING
Control Software:	CYPCUT	Laser Source Brand:	MAX Raycus
Laser Head Brand:	Raytools	Servo Motor Brand:	Yaskawa
Guiderail Brand:	HIWIN	Control System Brand:	Cypcut
Weight (KG):	3500 KG	Key Selling Points:	High Productivity Low Maintenance
Optical Lens Brand:	Wavelength	Warranty:	3 Years
Applicable Industries:	Building Material Shops, Manufacturing Plant, Machinery Repair Shops, Farms, Construction Works , Energy & Mining, Other, Advertising Company, Fabricating, Bicycle	Machinery Test Report:	Provided
Video Outgoing-inspection:	Provided	Warranty Of Core Components:	3 Years
Core Components:	Pressure Vessel, Motor, Gear, Gearbox, Engine, PLC, Quality Brighter Laser, Experienced Assembling Technique	Mode Of Operation:	Continuous Wave
Configuration:	Gantry Type	Products Handled:	Sheet Metal
Feature:	Programmable Servo Motor	Performance:	High Performance
Speed:	Quick Fast	Precision:	Accuracy
Maintenance:	Low Cost	Expericed Assembling Technique:	Reliable Quality
Experienced After Sales Service:	Solution And Training Offered

Application:	LASER CUTTING
Applicable Material:	Metal
Condition:	New
Laser Type:	Fiber Laser
Cutting Area:	1500mm*3000mm
Cutting Speed:	0~100m/min
Graphic Format Supported:	AI, PLT, DXF, BMP, Dst, Dwg, LAS, DXP
Cutting Thickness:	0~30mm
CNC Or Not:	Yes
Cooling Mode:	WATER COOLING
Control Software:	CYPCUT
Laser Source Brand:	MAX Raycus
Laser Head Brand:	Raytools
Servo Motor Brand:	Yaskawa
Guiderail Brand:	HIWIN
Control System Brand:	Cypcut
Weight (KG):	3500 KG
Key Selling Points:	High Productivity Low Maintenance
Optical Lens Brand:	Wavelength
Warranty:	3 Years
Applicable Industries:	Building Material Shops, Manufacturing Plant, Machinery Repair Shops, Farms, Construction Works , Energy & Mining, Other, Advertising Company, Fabricating, Bicycle
Machinery Test Report:	Provided
Video Outgoing-inspection:	Provided
Warranty Of Core Components:	3 Years
Core Components:	Pressure Vessel, Motor, Gear, Gearbox, Engine, PLC, Quality Brighter Laser, Experienced Assembling Technique
Mode Of Operation:	Continuous Wave
Configuration:	Gantry Type
Products Handled:	Sheet Metal
Feature:	Programmable Servo Motor
Performance:	High Performance
Speed:	Quick Fast
Precision:	Accuracy
Maintenance:	Low Cost
Expericed Assembling Technique:	Reliable Quality
Experienced After Sales Service:	Solution And Training Offered

1500x3000mm Gantry CNC Fiber Laser Cutting Machine for Metal

Gantry CNC Fiber Laser Cutting Machine with 1500mm×3000mm Cutting Area

Key Specifications

Attribute	Value
Application	Laser Cutting
Applicable Material	Metal
Laser Type	Fiber Laser
Cutting Area	1500mm × 3000mm
Cutting Speed	0-100m/min
Cutting Thickness	0-30mm
Control System	Cypcut
Weight	3500 KG
Warranty	3 years

Product Highlights

High productivity with cutting speeds up to 100m/min
Precision engineered with ±0.03mm positioning accuracy
Durable welded structural frame with annealing and abrasive blasting treatment
Premium components including Raycus/Max/IPG laser sources and Yaskawa servo motors
User-friendly Cypcut control system with multiple graphic format support
Low maintenance design with 3-year warranty on core components
17 years of laser cutting expertise from Shanghai-based manufacturer

Technical Specifications

Model: TF3015Edge
Laser Power Options: 1000W-20000W
Position Accuracy: ±0.03mm
Repeatability Accuracy: ±0.02mm
Power Supply: 3 phase 380V 50/60Hz
Table Load Capacity: 1500KG
Compatible Software: CorelDraw, AutoCAD, Photoshop, AI

Cutting Parameters

Material	Thickness (mm)	Assist Air	Speed (m/min)	Power (W)	Pressure (bar)	Header Height (mm)	Focus Height	Nozzle Type
MS (Q235B)	1	N2/Air	58-62	6000	12-16	0.5	0	Single:2.0
	2	N2/Air	31-36	6000	12-16	0.5	0-0.5	Single:2.0
	3	N2/Air	18-22	6000	12-16	0.5	-1-1.5	Single:2.0
SS (SUS304)	1	N2/Air	59-65	6000	12-16	0.5	0	Single:1.5
	2	N2/Air	32-38	6000	12-16	0.5	0-0.5	Single:2.0
	3	N2/Air	20-24	6000	12-16	0.5	-1-1.5	Single:2.0
